Central Carolina Scale sells and services Digi DC-100 Parts Counting Scales

DIGI DC 100

Counting Scale offers RS-232 and keyboard input ports.

Digi Model DC-100 features 2-line dot matrix LCD display that clearly shows numeric measurements and text messaging for job sequencing. With 1 MB of memory, unit stores over 1,500 items and offers internal resolution of 1,000,000 counts. Internal battery option provides over 30 hr of continuous use when mobile counting is required. Scale is suited for stockroom inventory, receiving parts verification, and parts scanning applications.

--------------------------------------------------------------------------------

Offering precise counting at an economical price, the DC-100 counting scale is ideal for stockroom inventory, receiving parts verification, and parts scanning applications. And with an RS-232 port and keyboard input port, the DC-100 compliments growing businesses. Plug in the optional keyboard wedge cable and you can type in part numbers, part names, etc... from your IBM keyboard. When multiple platform scales are needed, easily connect two external scales with a Y-cable. (keyboard not included)

Two line display showing numeric
measurement and text messaging
Bright backlit dot-matrix Liquid Crystal Display (LCD)
Internal setpoint capabilities
1MB memory (1500 items)
1,000,000 counting resolution
Keyboard/scanner port
Internal battery option
One RS-232 port
Two external scales via Y-cable

For simple operations, job sequencing or preprinted operator cards can help operators work quickly and efficiently. For non-English speaking operators, a user-definable operator card can be designed to direct users in their native language. This flexibility increases productivity and most importantly, accuracy.

Basic operation instructions

PRINTER COMPATIBILITY:
LP2824
SE300
LP2844 with custom set-up
ESCPOS compatible
INTERFACES:
1-IBM keyboard, 1-RS-232, 1-Ethernet
MEMORY:
1MB (2000PLU)*
PROGRAMMABLE PER ITEM:
ID code (32 digits), unit weight (5 digits), part number (32 digits), part name
(32 digits), location data (32 digits), inventory (8 digits), threshold (8 digits),
tare weight (5 digits), setpoints, lot number (set up with external keyboard)

* 1000 item memory maximum if all programmable items are utilized

OPTIONS / ACCESSORIES

78843 .......... Q56000 keyboard wedge scanner (requires 43860)
43860 .......... Cable, keyboard wedge
76485 .......... Zebra LP2824
77461 .......... Zebra LP2824 with label peeler
65617 .......... Label 2.25 x 4.5 with perf OTL
64661 .......... Cable for Zebra; 8-pin to 9-pin
32375 .......... 14 pin load cell connector
55853 .......... Rechargeable DC 100 Battery
53828 .......... Y cable multi-scale
82311 .......... Digi DC 100 Manual
Remote Scales (Bench or Floor Scales) to weigh larger amounts

For more info or to place an order, call (919) 776-7737 or email us
